| Specification of Amplifier Input/Output |
|
| Microphone / Line Input Channel |
3ch/3ch
|
| Microphone Input Impedance |
Parallel Type, 1.5KΩ@1KHz |
| Line Input Impedance |
Parallel Type(LINE1)/Nonparallel Type(LINE2,3), 1.5KΩ@1KHz.
|
| Maximum sensitivity of Microphone/Line Input |
-60/-30dBu |
| Total Output Power,240W@4Ω, 1KHz |
+98dB(MIC) |
| AMPLIFIER |
120W Mixer Amplifier |
| Recording Output Level |
0dBu, Nonparallel Type |
| Amplifier Output Level |
0dBu, Parallel Type. |
| Microphone Voice Quality |
500KHz~10KHz Variable Frequency, Gv=+/-12dB
|
| Line Voice Quality |
100Hz(Low)10KHz(High), Gv=+/-12dB
|
| Master Voice Quality |
100Hz(Low)10KHz(High), Gv=+/-12dB
|
| Speaker Output Specification |
|
| Rated Power |
120Wrms 4~8Ω
|
| Frequency |
+1, -3dB(Rated output, 20Hz ~ 20KHz)
|
| Negative Feed Back |
Less than 0.1% @30W / 4~8Ω(20Hz ~ 20KHz)
|
| Negative Feed Back |
Less than 0.1% @30W / 4~8Ω(20Hz ~ 20KHz)
|
| Signal/Noise Ratio |
More tan 100dB @Microphone (200Ω Cut-Off, 22~22KHz Band filter equipped)
|
| Voltage and Power Consumption |
200V ~,60Hz, max 250W
|
| Dimension and Net Weight (Before packing) |
483(W)× 88(H)× 257(D)mm,8kg
|
| THD |
< 0.5%
|
| Protection |
Dynamic level signal limiter, thermal protection, limiting & short circuit protection, Switch on delay.
|
